344206

Sigma-Aldrich

Disperse Red 1

Dye content 95 %

Sign Into View Organizational & Contract Pricing
All Photos(2)
Synonym(s):
N-Ethyl-N-(2-hydroxyethyl)-4-(4-nitrophenylazo)aniline
Empirical Formula (Hill Notation):
C16H18N4O3
CAS Number:
2872-52-8
Molecular Weight:
314.34
Colour Index Number:
11110
Beilstein:
5353614
EC Number:
220-704-3
MDL number:
MFCD00007312
PubChem Substance ID:
24861232
NACRES:
NA.23

form

powder

composition

Dye content, 95%

mp

160-162 °C (lit.)

λmax

502 nm

SMILES string

CCN(CCO)c1ccc(cc1)\N=N\c2ccc(cc2)[N+]([O-])=O

InChI

1S/C16H18N4O3/c1-2-19(11-12-21)15-7-3-13(4-8-15)17-18-14-5-9-16(10-6-14)20(22)23/h3-10,21H,2,11-12H2,1H3/b18-17+

InChI key

FOQABOMYTOFLPZ-ISLYRVAYSA-N

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

Disperse Red 1 (DR1) is a non-linear optical (NLO) material which is a chromophore used as an azobenzene dye. It can form a dipole network that can enhance the electro-optic effect of the non-linear components and can also improve the photorefractive effect.

Application

DR1 dye can be incorporated into hydroxypropyl cellulose (HPC) matrix which can be used as a coating that finds potential application in light storage and photonics. It can also be used to evaluate the third order non-linear susceptibility (X(3)) for 1,3-indandione based glasses for use in optical frequency conversion. Polytetrafluoroethylene (PTFE) membranes modified using DR1 maintain the mass transport and diffusion properties under direct light irradiation and can be used for water desalination applications.

Features and Benefits

This benchmark dipolar chromophore was incorporated into aromatic polymers to obtain model electrooptic polymer films.

Pictograms

Exclamation mark
GHS07

Signal Word

Warning

Hazard Statements

H317

Precautionary Statements

P280

Hazard Classifications

Skin Sens. 1

Storage Class Code

11 - Combustible Solids

WGK

WGK 3

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Documents related to the products that you have purchased in the past have been gathered in the Document Library for your convenience.

Visit the Document Library

Difficulty Finding Your Product Or Lot/Batch Number?

Product numbers are combined with Pack Sizes/Quantity when displayed on the website (example: T1503-25G). Please make sure you enter ONLY the product number in the Product Number field (example: T1503).

Example:

T1503
Product Number
-
25G
Pack Size/Quantity

Additional examples:

705578-5MG-PW

PL860-CGA/SHF-1EA

MMYOMAG-74K-13

1000309185

enter as 1.000309185)

Having trouble? Feel free to contact Technical Service for assistance.

Lot and Batch Numbers can be found on a product's label following the words 'Lot' or 'Batch'.

Aldrich Products

  • For a lot number such as TO09019TO, enter it as 09019TO (without the first two letters 'TO').

  • For a lot number with a filling-code such as 05427ES-021, enter it as 05427ES (without the filling-code '-021').

  • For a lot number with a filling-code such as STBB0728K9, enter it as STBB0728 without the filling-code 'K9'.

Not Finding What You Are Looking For?

In some cases, a COA may not be available online. If your search was unable to find the COA you can request one.

Request COA

A calix (4) resorcinarene-based hyper-structured molecule bearing disperse red 1 as the chromophore with enhanced photorefractive performance under non-electric field.
Zong W, et al.
Dyes and Pigments, 160(10), 579-586 (2019)
Water desalination using visible light by disperse red 1 modified PTFE membrane.
Fujiwara M.
Desalination, 404(1), 79-86 (2017)
Reversible light-induced solubility of disperse red 1 dye in a hydroxypropyl cellulose matrix.
Pawlicka A, et al.
Cellulose, 25(3), 2083-2090 (2018)
Polymeric electrooptic composite based on Disperse Red and its derivatives for use in photonics
Burunkova YE, et al.
Journal of Optical Technology, 77(10), 643-648 (2010)
Arylmethylene-1, 3-indandione based molecular glasses: Third order optical non-linearity.
Seniutinas G, et al.
Dyes and Pigments, 95(1), 33-40 (2012)
