MP54751010

Sigma-Aldrich

MakroPor, silicon membrane

thickness 475 μm, pore diameter 5.5 μm, pore size 12 μm (interpore distance), size 10 mm × 10 mm, pkg of 10 pieces

Sign Into View Organizational & Contract Pricing

About This Item

Linear Formula:
Si
UNSPSC Code:
12352103
NACRES:
NA.23

material

silicon membrane

description

FZ single crystal Si
Pore geometry: square arrangement

packaging

pkg of 10 pieces

size

10 mm × 10 mm

thickness

475 μm

pore size

12 μm (interpore distance)
5.5 μm pore diameter

compatibility

for use with applications requiring mechanical and chemical stability with high order of the pores

Looking for similar products? Visit Product Comparison Guide

Compare Similar Items

View Full Comparison

Show Differences

1 of 4

This Item
SRP0242SRP5325SRP0239
assay

≥95% (SDS-PAGE)

assay

≥70% (SDS-PAGE)

assay

≥70% (SDS-PAGE)

assay

≥70% (SDS-PAGE)

biological source

human

biological source

human

biological source

human

biological source

human

recombinant

expressed in HEK 293 cells

recombinant

expressed in baculovirus infected insect cells

recombinant

expressed in baculovirus infected Sf9 cells

recombinant

expressed in baculovirus infected insect cells

mol wt

calculated mol wt 69.5 kDa, observed mol wt 110-115 kDa (DTT-reduced.Protein migrates due to glycosylation.)

mol wt

88 kDa

mol wt

~89 kDa

mol wt

87.3 kDa

form

lyophilized

form

aqueous solution

form

buffered aqueous glycerol solution

form

aqueous solution

storage temp.

−20°C

storage temp.

−70°C

storage temp.

−70°C

storage temp.

−70°C

Application

Macro porous silicon is useful for applications requiring mechanical and chemical stability with high order of the pores. Our macro porous silicon membranes are manufactured from single crystal n-doped silicon wafers and possess pore diameter between 1 to 8 μm. The standard deviation of pore diameter and interpore distance for these porous silicon membrane materials is less than 5 %. These macro porous silicon finds applications in filtration, as platforms for multi-functional flow-through sensors, as fuels cells electrodes or micro reactors etc. They can also be used as templates for the fabrication of micro scale composites, such as tubes or wires by electrochemical deposition or by using polymer melts. We suggest using vacuum tweezers on the front side or polymer tweezers on the side faces.

Legal Information

Product of SmartMembranes-GmbH

Storage Class Code

13 - Non Combustible Solids

WGK

WGK 3

Flash Point(F)

Not applicable

Flash Point(C)

Not applicable
