SAMP2GNNK
Millex-GN for Samplicity G2, 0.20 µm, nylon, 33 mm, non-sterile
Select a Size
About This Item
material
polypropylene , polypropylene housing (PP)
description
Filter code GN
sterility
non-sterile
product category
syringe filters
product line
Millex™, Samplicity®
feature
hydrophilic
manufacturer/tradename
Millex™, Samplicity®
parameter
45 °C max. temp., 8.6 bar max. inlet pressure (125 psi)
technique(s)
UHPLC: suitable, analytical sample preparation: suitable
filtration area
4.5 cm2
hold-up volume
≤80 μL , after air purge
membrane diam.
33 mm
volume
1.7 mL
color
purple
pore size
0.2 μm
input
sample type organic solution(s)
sample type aqueous solution(s)
bubble point
≥2.9 bar, air with water
fitting
Luer-Lok® inlet/outlet connection Female Luer-Lok/Male Luer slip, inlet/outlet connection Luer-Lok® Female Luer-Lok/Male Luer slip
General description
- TM=["SAMPLICITY"] G2 Filtration System enables vacuum driven filtration of up to 8 samples at once, directly into HPLC vials<br />
- TM=["Millex"] Filters for the TM=["SAMPLICITY"] G2 System provide adaptor funnels and TM=["Millex"] 33 mm filters<br />
- TM=["SAMPLICITY"] G2 System has lower ergonomic impact than manual syringe filtration<br />
- Available in 0.20 µm and 0.45 µm pore sizes with TM=["Durapore"] PVDF, TM=["MILLIPORE EXPRESS"] PLUS PES, or nylon membranes
Available in 2 Pack Sizes:<br />SKU ending with NB (-------NB): 250 per pack<br />SKU ending with NK (-------NK): 1000 devices (4x 250 per pack)<br /><br />Applications:<br /> HPLC; Filtration of viscous or particulate laden samples for HPLC
Packaging
Other Notes
Legal Information
Disclaimer
Regulatory Information
Certificates of Analysis (COA)
Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.
Already Own This Product?
Find documentation for the products that you have recently purchased in the Document Library.
Related Content
The Samplicity® filtration system was developed to filter up to 8 samples directly into standard HPLC vials using vacuum-based filtration. The samples can then be used in downstream HPLC analysis. Given the high sensitivity of high performance liquid chromatography (HPLC) and ultra-high pressure liquid chromatography (UHPLC) analyses, it is critical to ensure that the filtered sample is not contaminated with extractables. This application note reports the results of tests for extractables from Millex Samplicity® LCR (0.45 μm hydrophilic PTFE) and LG (0.20 μm hydrophilic PTFE) filters using three commonly used HPLC detectors. The detectors used were an ultraviolet/visible (UV-Vis) spectrophotometer, a mass spectrometer and a fluorescence detector.
"Liquid chromatography mass spectrometry (LC-MS) and gas chromatography mass spectrometry (GC-MS) are being increasingly used in analysis of samples, not only in the biotechnology and pharmaceutical industries, but also more generally in the analysis, identification and quantitation of complex samples containing low levels of analytes. The advantages of LC-MS or GC-MS over other analytical techniques include high sensitivityand specificity for analyte detection and quantitation."
