322547
1,3-二氢-1,3,3-三甲基螺[2H-吲哚-2,3′-[3H]萘并[2,1-b][1,4]噁嗪]
≥98.0% (HPLC)
别名:
Photorome I
登录 查看组织和合同定价。
选择尺寸
关于此项目
经验公式（希尔记法）:
C22H20N2O
化学文摘社编号:
分子量:
328.41
NACRES:
NA.23
PubChem Substance ID:
UNSPSC Code:
12352103
MDL number:
InChI
1S/C22H20N2O/c1-21(2)17-10-6-7-11-18(17)24(3)22(21)14-23-20-16-9-5-4-8-15(16)12-13-19(20)25-22/h4-14H,1-3H3
SMILES string
CN1c2ccccc2C(C)(C)C13Oc4ccc5ccccc5c4N=C3
InChI key
CQTRKDFIQFOAQV-UHFFFAOYSA-N
assay
≥98.0% (HPLC)
mp
128-130 °C (lit.)
General description
1,3-Dihydro-1,3,3-trimethylspiro[2H-indole-2,3′-[3H]naphth[2,1-b][1,4]oxazine] (Photorome I) is an organic photochromic material that is used as a spirooxazine dye for use in molecular electronics. This dye changes to blue on irradiating with UV light.
Application
General applications of photochromic dye include: dosimetric materials, light controlling filters, recording films in printing processes, decorative paints, optical recording media and molecular electronic devices.1
Photorome I is a photochromic dye that can be used as a smart colorant for a variety of applications which include optical switches, printing materials, and ophthalmic lenses.
signalword
Warning
hcodes
Hazard Classifications
Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3
target_organs
Respiratory system
存储类别
11 - Combustible Solids
wgk
WGK 3
flash_point_f
Not applicable
flash_point_c
Not applicable
ppe
dust mask type N95 (US), Eyeshields, Gloves
NMR studies of the structure of the photoinduced forms of photochromic spironaphthoxazines.
Delbaere S, et al.
J. Chem. Soc. Perkin Trans. II, 1499-1502 (1997)
Cellulose nanocrystals (CNC) as carriers for a spirooxazine dye and its effect on photochromic efficiency.
Sun B, et al.
Carbohydrate Polymers, 111(8), 419-424 (2014)
Photochromic wool fabrics from a hybrid silica coating.
Cheng T, et al.
Textile Res., 77(12), 923-928 (2007)
Synthesis and properties of photochromic liquid-crystalline copolymers containing both spironaphthoxazine and cholesteryl groups.
Hattori H and Uryu T
Journal of Polymer Science Part A: Polymer Chemistry, 38(5), 887-894 (2000)
Interaction of a spirooxazine dye with latex and its photochromic efficiency on cellulosic paper.
Sun B, et al.
Carbohydrate Polymers, 95(1), 598-605 (2013)
