579211

Sigma-Aldrich

Tetrakis(dimethylamido)zirconium(IV)

electronic grade, ≥99.99% trace metals basis

Sign Into View Organizational & Contract Pricing

Synonym(s):
TDMAZ, Tetrakis(dimethylamino)zirconium(IV)
Linear Formula:
[(CH3)2N]4Zr
CAS Number:
Molecular Weight:
267.53
MDL number:
PubChem Substance ID:
NACRES:
NA.23

grade

electronic grade

Quality Level

Assay

≥99.99% trace metals basis

form

solid

reaction suitability

core: zirconium

mp

57-60 °C (lit.)

storage temp.

2-8°C

SMILES string

CN(C)[Zr](N(C)C)(N(C)C)N(C)C

InChI

1S/4C2H6N.Zr/c4*1-3-2;/h4*1-2H3;/q4*-1;+4

InChI key

DWCMDRNGBIZOQL-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Application

Tetrakis(dimethylamido) zirconium (IV) may be used as a precursor for atomic layer deposition of zirconium which find applications ranging from gas sensors to high-k dielectrics in microelectronics.

Pictograms

FlameExclamation mark

Signal Word

Danger

Hazard Classifications

Eye Irrit. 2 - Flam. Sol. 1 - Skin Irrit. 2 - STOT SE 3 - Water-react 2

Target Organs

Respiratory system

Supplementary Hazards

Storage Class Code

4.3 - Hazardous materials, which set free flammable gases upon contact with water

WGK

WGK 3

Flash Point(F)

No data available

Flash Point(C)

No data available

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Documents related to the products that you have purchased in the past have been gathered in the Document Library for your convenience.

Visit the Document Library

Difficulty Finding Your Product Or Lot/Batch Number?

Product numbers are combined with Pack Sizes/Quantity when displayed on the website (example: T1503-25G). Please make sure you enter ONLY the product number in the Product Number field (example: T1503).

Example:

T1503
Product Number
-
25G
Pack Size/Quantity

Additional examples:

705578-5MG-PW

PL860-CGA/SHF-1EA

MMYOMAG-74K-13

1000309185

enter as 1.000309185)

Having trouble? Feel free to contact Technical Service for assistance.

Lot and Batch Numbers can be found on a product's label following the words 'Lot' or 'Batch'.

Aldrich Products

  • For a lot number such as TO09019TO, enter it as 09019TO (without the first two letters 'TO').

  • For a lot number with a filling-code such as 05427ES-021, enter it as 05427ES (without the filling-code '-021').

  • For a lot number with a filling-code such as STBB0728K9, enter it as STBB0728 without the filling-code 'K9'.

Not Finding What You Are Looking For?

In some cases, a COA may not be available online. If your search was unable to find the COA you can request one.

Request COA

Atomic layer deposition of ZrO2 and HfO2 nanotubes by template replication
Gu D, et al.
Electrochemical and Solid-State Letters, 12.4, K25-K28 (2009)
Surface morphology and crystallinity control in the atomic layer deposition (ALD) of hafnium and zirconium oxide thin films.
Hausmann DM & Gordon RG
Journal of Crystal Growth, 249.1, 251-261 (2003)
