136891

cis-1,2,3,6-Tetrahydrophthalic anhydride

95%

Synonym(s):

cis-4-Cyclohexene-1,2-dicarboxylic anhydride

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C8H8O3
CAS Number:
935-79-5
Molecular Weight:
152.15
UNSPSC Code:
12162002
NACRES:
NA.23
PubChem Substance ID:
24848300
EC Number:
213-308-7
Beilstein/REAXYS Number:
82341
MDL number:
MFCD00005916

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

cis-1,2,3,6-Tetrahydrophthalic anhydride, 95%

InChI key

KMOUUZVZFBCRAM-OLQVQODUSA-N

InChI

1S/C8H8O3/c9-7-5-3-1-2-4-6(5)8(10)11-7/h1-2,5-6H,3-4H2/t5-,6+

SMILES string

[H][C@@]12CC=CC[C@]1([H])C(=O)OC2=O

vapor density

5.2 (vs air)

vapor pressure

<0.01 mmHg ( 20 °C)

assay

95%

form

flakes

mp

97-103 °C (lit.)

Quality Level

100

Looking for similar products? Visit Product Comparison Guide

Related Categories

Application

cis-1,2,3,6-Tetrahydrophthalic anhydride (THPA) can be used as:
  • A curing agent for epoxides.
  • A chemical modifier in the modification of polystyrene via Friedel-Crafts acylation for enhancing the thermal stability of the polymer.
  • A reactant for the synthesis of cis-tetrahydroisoindole-1,3-dione derivatives and cyclic diimides.

pictograms

Health hazardCorrosion
GHS08,GHS05

signalword

Danger

Hazard Classifications

Aquatic Chronic 3 - Eye Dam. 1 - Resp. Sens. 1 - Skin Sens. 1

Storage Class

8A - Combustible corrosive hazardous materials

wgk

WGK 3

flash_point_f

312.8 °F - closed cup

flash_point_c

156 °C - closed cup

ppe

dust mask type N95 (US), Eyeshields, Faceshields, Gloves

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
STBD4960V
STBD0460V
STBB3135V
STBB3135
S85964

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Influence of cure schedule and stoichiometry on the dynamic mechanical behaviour of tetrafunctional epoxy resins cured with anhydrides
Guerrero P, et al.
Polymer, 37(11), 2195-2200 (1996)
Polymer networks derived from curing of epoxidised linseed oil: influence of different catalysts and anhydride hardeners
Boquillon N and Fringant C
Polymer, 41(24), 8603-8613 (2000)
Chemical modification of polystyrene?IV. Electrophilic substitution of polystyrene with cis-1, 2, 3, 6 tetrahydrophthalic anhydride
Biswas M and Chatterjee S
European Polymer Journal, 19(4), 317-320 (1983)
Cong Zhang et al.
Journal of controlled release : official journal of the Controlled Release Society, 226, 193-204 (2016-02-21)
Stepwise pH-responsive nanoparticle system containing charge reversible pullulan-based (CAPL) shell and poly(β-amino ester) (PBAE)/poly(lactic-co-glycolic acid) (PLAG) core is designed to be used as carriers of paclitaxel (PTX) and combretastatin A4 (CA4) for combining antiangiogenesis and chemotherapy to treat hepatocellular carcinoma
Montmorillonite K-10 supported one-pot synthesis of some symmetric diimides and 3a, 4, 7, 7a-tetrahydroisoindole-1, 3-dione derivatives under solvent-free conditions using microwaves
Habibi D and Marvi O
J. Serb. Chem. Soc., 70(4), 579-583 (2005)
