163260

4-Chloro-7-nitrobenzofurazan

98%

Synonym(s):

4-Chloro-7-nitro-1,2,3-benzoxadiazole, NBD-chloride

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):
C6H2ClN3O3
CAS Number:
10199-89-0
Molecular Weight:
199.55
UNSPSC Code:
12352100
NACRES:
NA.22
PubChem Substance ID:
24849737
EC Number:
233-496-4
Beilstein/REAXYS Number:
614212
MDL number:
MFCD00005808
Assay:
98%
Form:
powder
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Quality Level

100

assay

98%

form

powder

mp

97-99 °C (lit.)

solubility

chloroform: soluble 50 mg/mL, clear to slightly hazy, faintly yellow to yellow

functional group

chloro, nitro

SMILES string

[O-][N+](=O)c1ccc(Cl)c2nonc12

InChI

1S/C6H2ClN3O3/c7-3-1-2-4(10(11)12)6-5(3)8-13-9-6/h1-2H

InChI key

IGHBXJSNZCFXNK-UHFFFAOYSA-N

General description

4-Chloro-7-nitrobenzofurazan (NBD-Cl) is a highly sensitive chromogenic and fluorogenic reagent. It is reported to react spontaneously with trans-1-methoxy-3-(trimethylsilyloxy)-1,3-butadiene (Danishefsky′s diene), to afford regioselectively the silyl enol ether, via normal electron-demand Diels-Alder (NEDDA) reaction. A study of the molecular structure, vibrational spectra and NBO (Natural Bond Orbital) analysis of NBD–Cl has been undertaken. Its utility as a pre-column derivatization agent has been examined.

Application

4-Chloro-7-nitrobenzofurazan (NBD-chloride) was used in the following studies:
  • Synthesis of fluorescent phospholipid-derivative, NBD-didecanoylphosphatidylethanolamine
  • Synthesis of functionalized hydroxynaphthofurazan.
  • Spectrophotometric and spectrofluorometric determination of clemastine hydrogen fumarate, loratadine, losartan potassium and ramipril in pharmaceutical formulations.
  • Synthesis of 7-nitrobenzofurazan (NBD)-labeled maleimide, via Diels-Alder reaction.

Still not finding the right product?

Explore all of our products under 4-Chloro-7-nitrobenzofurazan

pictograms

Exclamation mark
GHS07

signalword

Warning

hcodes

H315,H319

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2

Storage Class

11 - Combustible Solids

wgk

WGK 3

ppe

dust mask type N95 (US), Eyeshields, Faceshields, Gloves

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
BCCP2184
BCCN5528
STBL4346
STBL4345
STBL0661

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Articles

Diels–Alder Reaction

The Diels–Alder reaction is the reaction between a conjugated diene and an alkene (dienophile) to form unsaturated six-membered rings. It is also referred to as a cycloaddition.

Gholamreza Bahrami et al.
Journal of chromatography. B, Analytical technologies in the biomedical and life sciences, 857(2), 322-326 (2007-08-21)
A sensitive and rapid high-performance liquid chromatographic method for the analysis of fluvoxamine, a selective serotonin reuptake inhibitor in human serum, is described using 4-chloro-7-nitrobenzofurazan as pre-column derivatization agent. The drug and an internal standard (fluoxetine) were extracted from 0.25
Marco Filice et al.
Organic & biomolecular chemistry, 9(15), 5535-5540 (2011-06-23)
Lipase B from Candida antarctica (CAL-B) has been site-directedly modified by the introduction of a trans,trans-hexadiene moiety onto lipase molecules, identified by MALDI-TOF. This modification on CAL-B permitted its immobilization on Q-Sepharose supports in excellent yields (>95%) when native lipase
4-Chloro-7-nitrobenzofurazan as a Diels-Alder reagent. A facile access to highly functionalized naphthofurazans.
Vichard D, et al.
Tetrahedron Letters, 42(43), 7571-7574 (2001)
