Merck
CN

194905

12-Crown-4

98%

Synonym(s):

1,4,7,10-Tetraoxacyclododecane

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C8H16O4
CAS Number:
294-93-9
Molecular Weight:
176.21
UNSPSC Code:
12352005
NACRES:
NA.22
PubChem Substance ID:
24851661
EC Number:
206-036-5
Beilstein/REAXYS Number:
1363064
MDL number:
MFCD00005103

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

12-Crown-4, 98%

InChI key

XQQZRZQVBFHBHL-UHFFFAOYSA-N

InChI

1S/C8H16O4/c1-2-10-5-6-12-8-7-11-4-3-9-1/h1-8H2

SMILES string

C1COCCOCCOCCO1

assay

98%

form

liquid

refractive index

n20/D 1.463 (lit.)

bp

61-70 °C/0.5 mmHg (lit.)

mp

16 °C (lit.)

density

1.089 g/mL at 25 °C (lit.)

functional group

ether

Quality Level

100

Looking for similar products? Visit Product Comparison Guide

Application

12-Crown-4 can be used as:
  • A promoter in the synthesis of poly(diethylsiloxane) (PDES) from monomer hexaethylcyclotrisiloxane using NaOH as a catalyst via anionic ring-opening polymerization.
  • As an additive in the preparation of triarylmethane derivatives by palladium-catalyzed cross coupling reaction of aryl bromides with diarylmethane derivatives.
  • A phase transfer catalyst in organic synthesis.

General description

12-Crown-4 is a crown ether generally used as a ligand in coordination chemistry. It is also known as lithium ionophore because of its strong chelating property specific to lithium cation.

pictograms

Skull and crossbones
GHS06

signalword

Danger

hcodes

H330

Hazard Classifications

Acute Tox. 1 Inhalation

Storage Class

6.1A - Combustible acute toxic Cat. 1 and 2 / very toxic hazardous materials

wgk

WGK 3

flash_point_f

235.4 °F - closed cup

flash_point_c

113 °C - closed cup

ppe

Eyeshields, Faceshields, Gloves, type ABEK (EN14387) respirator filter

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
MKCX7242
MKCV0403
MKCR8459
MKCL2187
MKCL0309

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Free inorganic, organic, and organometallic ions by treatment of their lithium salts with 12-crown-4
Power PP, et al.
Accounts of Chemical Research, 21(4), 147-153 (1988)
1, 4, 7, 10-Tetraoxacyclododecane (12-crown-4) as neutral carrier for lithium ion in lithium ion selective electrode
Gadzekpo VPY and Christian GD
Analytical Letters, 16(17-18), 1371-1380 (1983)
Mazhar Ali Abbasi et al.
Sensors (Basel, Switzerland), 12(11), 15424-15437 (2012-12-04)
In this study honeycomb-like NiO nanostructures were grown on nickel foam by a simple hydrothermal growth method. The NiO nanostructures were characterized by field emission electron microscopy (FESEM), high resolution transmission electron microscopy (HRTEM) and X-ray diffraction (XRD) techniques. The
Zehra Edis et al.
Pathogens (Basel, Switzerland), 8(4) (2019-10-30)
Antimicrobial agents containing symmetrical triiodides complexes with halogen bonding may release free iodine molecules in a controlled manner. This happens due to interactions with the plasma membrane of microorganisms which lead to changes in the structure of the triiodide anion.
Preparation of poly (diethylsiloxane) with the NaOH/12-crown-4 catalyst
Hedden RC and Cohen C
Polymer, 41(18), 6975-6979 (2000)
