391980

1,2,4,5-Tetracyanobenzene

97%

Synonym(s):

1,2,4,5-Benzenetetracarbonitrile, Pyromellitic acid tetranitrile

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
C6H2(CN)4
CAS Number:
712-74-3
Molecular Weight:
178.15
UNSPSC Code:
12352100
NACRES:
NA.22
PubChem Substance ID:
24864415
MDL number:
MFCD00043481
Beilstein/REAXYS Number:
1875027
Assay:
97%
Form:
solid

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

InChI

1S/C10H2N4/c11-3-7-1-8(4-12)10(6-14)2-9(7)5-13/h1-2H

SMILES string

N#Cc1cc(C#N)c(cc1C#N)C#N

InChI key

FAAXSAZENACQBT-UHFFFAOYSA-N

assay

97%

form

solid

mp

265-268 °C (lit.)

solubility

acetone: soluble 25 mg/mL, clear, colorless to yellow

functional group

nitrile

Quality Level

200

Related Categories

General description

1,2,4,5-Tetracyanobenzene (TCNB, TCB) is a tetra substituted benzene. The IR and raman spectra of TCNB and its 1:1 complex with durene has been recorded. The time-resolved linear dichroism spectroscopic study of hexamethylbenzene-1,2,4,5-tetracyanobenzene charge-transfer complex has been investigated. The influence of magnetic field on the charge-transfer fluorescence of 1,2,4,5-tetracyanobenzene-doped poly(N-vinylcarbazole) thin film has been studied.

Application

1,2,4,5-Tetracyanobenzene (TCB, TCNB) is suitable reagent used in the synthesis of o-3,4-dimethyltetrathiafulvalene (o-Me2TTF)-1,2,4,5-tetracyanobenzene (TCNB) 1:1 complex and radiative exciplexes of TCB in non-polar solvents.

1,2,4,5-Tetracyanobenzene (Pyromellitic acid tetranitrile, PMTN, TCB, TCNB, 1,2,4,5-benzenetetracarbonitrile ) may be used in the following studies:
  • Solid-state diffusion of TCNB into 9-methylanthracene molecular crystal nanorods forming cocrystal nanorods.
  • Synthesis of copper polyphthalocyanine (CuPPC) thin films, an elementoorganic semiconductor.
  • Preparation of charge transfer (CT) nanocrystallites which may have a potential use in nanofluidics to observe the rotational motion of nanoobjects.
  • Hydrothermal synthesis of Co2(terpy)2(btec)•H2O (terpy = 2,2′:6′,2"-terpyridine, btec = 1,2,4,5-benzenetetracarboxylate).

pictograms

Skull and crossbones
GHS06

signalword

Danger

Hazard Classifications

Acute Tox. 2 Oral

Storage Class

6.1A - Combustible acute toxic Cat. 1 and 2 / very toxic hazardous materials

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

Eyeshields, Faceshields, Gloves, type P2 (EN 143) respirator cartridges

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
0000231507
0000231507
0000131137
0000131166
0000120620

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Formation of cocrystal nanorods by solid-state reaction of tetracyanobenzene in 9-methylanthracene molecular crystal nanorods.
Al-Kaysi RO, et al.
Crystal Growth & Design, 9(4), 1780-1785 (2009)
Structural Studies of the 1: 1 Complex of o-3, 4-Dimethyltetrathiafulvalene (o-Me2TTF) and 1, 2, 4, 5-Tetracyanobenzene (TCNB).
Reinheimer EW, et al.
Journal of Chemical Crystallography, 40(6), 514-519 (2010)
Inelastic and quasielastic neutron scattering and IR and R spectroscopic studies of 1, 2, 4, 5-tetracyanobenzene (TCNB)-1, 2, 4, 5-tetramethylbenzene (durene) complex.
Bator G, et al.
Phase Transitions, 80(6-7), 489-500 (2007)
Radiative exciplexes of 1, 2, 4, 5-Tetracyanobenzene with sterically hindered alkylbenzenes.
Zhou J, et al.
The Journal of Physical Chemistry A, 107(40), 8319-8326 (2003)
Nanosized crystallites of charge-transfer complex of 9-methylanthracene and 1, 2, 4, 5-tetracyanobenzene for bright and optically anisotropic fluorescent probes.
Hosaka N, et al.
Applied Physics Letters, 92(11), 113305-113305 (2008)
