398802

Tetra(ethylene glycol) diacrylate

technical grade, cross-linking reagent polymerization reactions, acrylate, 100-150 ppm HQ as inhibitor, 150-200 ppm MEHQ as inhibitor

Synonym(s):

TTEGDA

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
(H2C=CHCO2CH2CH2OCH2CH2)2O
CAS Number:
17831-71-9
Molecular Weight:
302.32
NACRES:
NA.23
PubChem Substance ID:
24864768
UNSPSC Code:
12162002
EC Number:
241-789-3
MDL number:
MFCD00008630

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Tetra(ethylene glycol) diacrylate, technical grade, contains 100-150 ppm HQ as inhibitor, 150-200 ppm MEHQ as inhibitor

InChI key

HCLJOFJIQIJXHS-UHFFFAOYSA-N

InChI

1S/C14H22O7/c1-3-13(15)20-11-9-18-7-5-17-6-8-19-10-12-21-14(16)4-2/h3-4H,1-2,5-12H2

SMILES string

C=CC(=O)OCCOCCOCCOCCOC(=O)C=C

grade

technical grade

form

liquid

contains

100-150 ppm HQ as inhibitor, 150-200 ppm MEHQ as inhibitor

reaction suitability

reagent type: cross-linking reagent
reaction type: Polymerization Reactions

refractive index

n20/D 1.465 (lit.)

density

1.11 g/mL at 25 °C (lit.)

Ω-end

acrylate

α-end

acrylate

polymer architecture

shape: linear
functionality: homobifunctional

Quality Level

100

Related Categories

General description

Tetra(ethylene glycol) diacrylate is a long-chain hydrophilic, crosslinking monomer widely used in the preparation of gel polymer electrolytes for Li-ion polymer batteries, acrylic polymers, and coating materials.

pictograms

Exclamation mark
GHS07

signalword

Warning

hcodes

H302,H317

Hazard Classifications

Acute Tox. 4 Oral - Skin Sens. 1

Storage Class

10 - Combustible liquids

wgk

WGK 2

flash_point_f

235.4 °F - closed cup

flash_point_c

113 °C - closed cup

ppe

Faceshields, Gloves, Goggles, type ABEK (EN14387) respirator filter

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
MKDB0116
MKDB0508
MKCZ9700
MKCX6379
MKCZ3807

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

J R Nethercott et al.
Journal of occupational medicine. : official publication of the Industrial Medical Association, 26(7), 513-516 (1984-07-01)
A woman who worked as a materials handler in a plant manufacturing acrylated chemicals developed allergic contact allergy to tetraethylene glycol diacrylate (TTEGDA). Four co-workers experienced skin irritation 12 to 36 hours after skin contact with TTEGDA but had no
Tetraethylene glycol diacrylate.
American Industrial Hygiene Association journal, 42(11), B49-B50 (1981-11-01)
Sean Brahim et al.
Biomacromolecules, 4(3), 497-503 (2003-05-14)
An amphiphilic hydrogel network was synthesized from a cross-linked poly(2-hydroxyethyl methacrylate) backbone copolymerized with the monomers 3-(trimethoxysilyl)propyl methacrylate (PMA) and dimethylaminoethyl methacrylate (DMAEMA) using tetraethylene glycol diacrylate (TEGDA) as cross-linker and using the radical initiator system comprising N,N,N',N'-tetramethylethylenediamine and ammonium
Electrochemical properties of poly(tetra ethylene glycol diacrylate)-based gel electrolytes for lithium-ion polymer batteries
Hyun-Soo Kim, et al.
Journal of Power Sources, 119-121, 482-486 (2003)
Synthesis of electron beam cured free-standing ion-gel membranes for organic electronics applications
Marco Mennillo, et al.
Journal of Polymer Science Part A: Polymer Chemistry, 54, 2352-2360 (2016)
