480797

Ethylene glycol diacrylate

90%, technical grade, cross-linking reagent polymerization reactions, acrylate

Synonym(s):

Polyethylene glycol, Ethylene diacrylate, Ethylene glycol dipropenoate

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

Linear Formula:
(H2C=CHCO2CH2-)2
CAS Number:
2274-11-5
Molecular Weight:
170.16
NACRES:
NA.23
PubChem Substance ID:
24871719
UNSPSC Code:
12162002
EC Number:
218-886-4
MDL number:
MFCD00008629
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Ethylene glycol diacrylate, 90%, technical grade

Quality Level

100

grade

technical grade

assay

90%

reaction suitability

reagent type: cross-linking reagent
reaction type: Polymerization Reactions

refractive index

n20/D 1.453 (lit.)

bp

66-68 °C/2 mmHg (lit.)

density

1.094 g/mL at 25 °C (lit.)

Ω-end

acrylate

α-end

acrylate

polymer architecture

shape: linear
functionality: homobifunctional

storage temp.

2-8°C

SMILES string

C=CC(=O)OCCOC(=O)C=C

InChI

1S/C8H10O4/c1-3-7(9)11-5-6-12-8(10)4-2/h3-4H,1-2,5-6H2

InChI key

KUDUQBURMYMBIJ-UHFFFAOYSA-N

Still not finding the right product?

Explore all of our products under Ethylene glycol diacrylate

pictograms

Skull and crossbonesEnvironment
GHS06,GHS09

signalword

Danger

Hazard Classifications

Acute Tox. 3 Oral - Acute Tox. 4 Dermal - Acute Tox. 4 Inhalation - Aquatic Chronic 2 - Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

target_organs

Respiratory system

Storage Class

6.1C - Combustible acute toxic Cat.3 / toxic compounds or compounds which causing chronic effects

flash_point_f

213.8 °F - closed cup

flash_point_c

101 °C - closed cup

ppe

Eyeshields, Faceshields, Gloves, type ABEK (EN14387) respirator filter

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
MKCZ2423
MKCZ2421
BCCL0768
MKCS3355
MKCJ6019

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Hossein Sojoudi et al.
ACS applied materials & interfaces, 11(7), 7330-7337 (2019-01-29)
Blockage of pipelines due to accretion of salt particles is detrimental in desalination and water-harvesting industries as they compromise productivity, while increasing maintenance costs. We present a micro-/nanoscale approach to study fundamentals of scale formation, deposition, and adhesion to engineered
Rebecca E Dey et al.
Journal of biomedical materials research. Part A, 106(1), 255-264 (2017-09-12)
There is a clinical need for a synthetic bone graft substitute that can be used at sites of surgical intervention to promote bone regeneration. Poly(vinylphosphonic acid-co-acrylic acid) (PVPA-co-AA) has recently been identified as a potential candidate for use in bone

Global Trade Item Number

SKUGTIN
480797-5ML04061837890024
480797-25ML04061837890017
