description
Resistivity: 1.5 mΩ/sq, per 25 μm (by digital printing using DIMATIX DMP 2800-Cartridge 10 pL, oven curing at 150 °C for 30 min.)
Quality Level
form
liquid
color
dark brown to blue
surface tension
29 mN/m±3 mN/m
viscosity
13 mPa.s±3 mPa.s(20 °C)
capacity
20±1 % loading (Nanoparticles loading)
storage temp.
2-8°C
Related Categories
General description
Smart′Ink S-CS01130 conductive ink shows improved jetting performance and is successfully used on different tools such as Drop on Demand (DOD) inkjet printer FUJIFILM Dimatix, or such as digital micro-dispensing inkjet printer Microdrop and Microfab.
Features and Benefits
- Very high electrical conductivity.
- Low curing temperature for printing on flexible substrates.
- Non CMR ink.
- Compatible with various curing process including photonic, IR, low vacuum oven and thermal.
- Unchanged conductivity on bending.
- Good adhesion (5B-ASTM D3359) on various flexible substrates (PET, PEN and Kapton).Recommended surface treatment: temperature stabilization, argon plasma.
Preparation Note
- Qualified printheads: RICOH (MH5420), XAAR (1003 GS6, 128), KONIKA MINOLTA (KM512SHx, KM1024iMHE, KM1024LHB), FUJIFILM (Dimatrix DMP series cartridge)
- Storage stability: 6 months (fridge)
- Sintering conditions:
NIR: few seconds for 4-10mW.cm.
Photonic curing: <100 ms for 3-10mW.cm.
- Smart′Ink S-CS01130 conductive ink is warmed to room temperature (about 10 minutes) and left for 5 minutes in an ultrasonic bath in order to get rid of any aggregates.
- Filtration on a 0.45 μm PTFE filter syringe to avoid any nozzles clogging.
Legal Information
Signal Word
Danger
Hazard Statements
Precautionary Statements
Hazard Classifications
Aquatic Acute 1 - Aquatic Chronic 1 - Asp. Tox. 1 - Eye Dam. 1 - Flam. Liq. 3 - Skin Irrit. 2 - Skin Sens. 1
Storage Class Code
3 - Flammable liquids
WGK
WGK 3
Flash Point(F)
104.0 °F
Flash Point(C)
40 °C
