B9750

Benzophenone-3,3′,4,4′-tetracarboxylic dianhydride

98%

Synonym(s):

4,4′-Carbonyldiphthalic anhydride

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C17H6O7
CAS Number:
2421-28-5
Molecular Weight:
322.23
UNSPSC Code:
12162002
NACRES:
NA.23
PubChem Substance ID:
24892154
EC Number:
219-348-1
Beilstein/REAXYS Number:
761777
MDL number:
MFCD00005923

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Benzophenone-3,3′,4,4′-tetracarboxylic dianhydride, 98%

InChI key

VQVIHDPBMFABCQ-UHFFFAOYSA-N

InChI

1S/C17H6O7/c18-13(7-1-3-9-11(5-7)16(21)23-14(9)19)8-2-4-10-12(6-8)17(22)24-15(10)20/h1-6H

SMILES string

O=C1OC(=O)c2cc(ccc12)C(=O)c3ccc4C(=O)OC(=O)c4c3

vapor density

1.4 (vs air)

vapor pressure

<0.1 mmHg ( 0 °C)

assay

98%

form

powder

autoignition temp.

975 °F

expl. lim.

16 %

mp

218-222 °C (lit.)

Quality Level

200

Looking for similar products? Visit Product Comparison Guide

Related Categories

Application

Used in the synthesis of polyimides.

General description

Benzophenone-3,3′,4,4′-tetracarboxylic acid is formed by hydrolysis, it can be converted to the dianhydride by treating with Ac2O (molar ratio 4 to 1 of acid).The dianhydride is used to synthesize polyimides, which are highly flexible in nature due to the presence of keto and carbonyl groups in the dianhydride molecule. The keto and carbonyl groups subsequently increase the spacing between the imide rings enhancing the solubility and processibility.

pictograms

Exclamation mark
GHS07

signalword

Warning

hcodes

H319,H335

Hazard Classifications

Eye Irrit. 2 - STOT SE 3

target_organs

Respiratory system

Storage Class

11 - Combustible Solids

wgk

WGK 1

ppe

dust mask type N95 (US), Eyeshields, Gloves
