Merck
CN

D97754

Diethyl malonate

ReagentPlus®, 99%

Synonym(s):

Malonic acid diethyl ester

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
CH2(COOC2H5)2
CAS Number:
105-53-3
Molecular Weight:
160.17
UNSPSC Code:
12352100
NACRES:
NA.22
PubChem Substance ID:
24894329
EC Number:
203-305-9
Beilstein/REAXYS Number:
774687
MDL number:
MFCD00009195
Assay:
99%
Form:
liquid

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

InChI key

IYXGSMUGOJNHAZ-UHFFFAOYSA-N

InChI

1S/C7H12O4/c1-3-10-6(8)5-7(9)11-4-2/h3-5H2,1-2H3

SMILES string

CCOC(=O)CC(=O)OCC

vapor density

5.52 (vs air)

vapor pressure

1 mmHg ( 40 °C)

product line

ReagentPlus®

assay

99%

form

liquid

Quality Level

200

bp

199 °C (lit.)

mp

−51-−50 °C (lit.)

density

1.055 g/mL at 25 °C (lit.)

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

Diethyl malonate is diethyl ester of malonic acid. It is widely used as a versatile building block for introducing the malonate functional group into molecules. Acylation of diethyl malonate using magnesium chloride and triethylamine is reported. K2CO3-catalyzed 1,4-addition reaction of diethyl malonate with various substituted 1,2-allenic ketones yields polyfunctionalized β,γ-unsaturated enones.

Application

Diethyl malonate was used to investigate Knoevenagel condensation reactions in microreactor using zeolite catalysts obtained by grafting amino groups onto NaX and CsNaX zeolites. It may be used in the synthesis of diethyl benzylidenemalonate by base catalyzed Knoevenagel condensation with benzaldehyde. It may be used in the synthesis of α-aryl malonates.

Packaging

Packaged in glass bottles

Legal Information

ReagentPlus is a registered trademark of Merck KGaA, Darmstadt, Germany

pictograms

Exclamation mark
GHS07

signalword

Warning

hcodes

H319

Hazard Classifications

Eye Irrit. 2

Storage Class

10 - Combustible liquids

wgk

WGK 1

flash_point_f

199.4 °F - closed cup

flash_point_c

93 °C - closed cup

ppe

Eyeshields, Gloves, multi-purpose combination respirator cartridge (US)

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
SDBB7517
SDBB6360
SDBB3951
SDBB0477
STBL2460

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Shengming Ma et al.
The Journal of organic chemistry, 68(23), 8996-9002 (2003-11-08)
The K2CO3 (10 mol %)-catalyzed 1,4-addition reaction of diethyl malonate with various substituted 1,2-allenic ketones leading to polyfunctionalized beta,gamma-unsaturated enones 3 or 4 was studied. With 3-unsubstituted 1-substituted-1,2-allenyl ketones, the highly selective formation of beta,gamma-unsaturated enones 4 was observed; with
Solvent-free organocatalytic Michael addition of diethyl malonate to nitroalkenes: the practical synthesis of Pregabalin and ?-nitrobutyric acid derivatives
J Liu, et al.
Tetrahedron, 67, 636-640 (2011)
Edward J Hennessy et al.
Organic letters, 4(2), 269-272 (2002-02-14)
[reaction: see text] A general method for the synthesis of alpha-aryl malonates is described. The coupling of an aryl iodide and diethyl malonate in the presence of Cs(2)CO(3) and catalytic amounts of copper(I) iodide and 2-phenylphenol affords the alpha-aryl malonate
Integration of heterogeneous catalysts into complex synthetic routes: sequential vs. one-pot reactions in a (Knoevenagel+ Mukaiyama-Michael+ hydrogenation+ transesterification) sequence.
Fraile JM, et al.
Catalysis Science & Technology, 3(2), 436-443 (2013)
Procedures for the acylation of diethyl malonate and ethyl acetoacetate with acid chlorides using tertiary amine bases and magnesium chloride.
Rathke MW and Cowan PJ.
The Journal of Organic Chemistry, 50(15), 2622-2624 (1985)
View All Related Papers

Articles

Knoevenagel Condensation Reaction

Knoevenagel Condensation is an organic reaction named after Emil Knoevenagel. It is a classic C-C bond formation reaction and a modification of the Aldol Condensation.
