8.07059

Diethyl oxalate

Name: Diethyl oxalate
Brand: MM

for synthesis

Synonym(s):

Diethyl oxalate, Oxalic acid diethyl ester

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):

C₆H₁₀O₄

CAS Number:

95-92-1

Molecular Weight:

146.14

UNSPSC Code:

12352108

EC Index Number:

202-464-1

NACRES:

NA.22

MDL number:

MFCD00009119

Assay:

≥98.0% (GC)

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

vapor pressure

0.27 hPa ( 20 °C)

Quality Segment

200

assay

≥98.0% (GC)

autoignition temp.

410 °C

potency

400 mg/kg LD₅₀, oral (Rat)

expl. lim.

0.42-2.67 % (v/v)

bp

182-186 °C

mp

-41 °C

transition temp

flash point 75 °C

density

1.08 g/cm³ at 20 °C

storage temp.

2-30°C

SMILES string

O(CC)C(=O)C(=O)OCC

InChI

1S/C6H10O4/c1-3-9-5(7)6(8)10-4-2/h3-4H2,1-2H3

InChI key

WYACBZDAHNBPPB-UHFFFAOYSA-N

Description

Analysis Note

Assay (GC, area%): ≥ 98.0 % (a/a)
Density (d 20 °C/ 4 °C): 1.076 - 1.079
Identity (IR): passes test

Still not finding the right product?

Explore all of our products under Diethyl oxalate

pictograms

GHS05,GHS07,GHS08

signalword

Danger

hcodes

H302 - H314 - H373

pcodes

P260 - P280 - P301 + P312 - P303 + P361 + P353 - P305 + P351 + P338 - P314

Hazard Classifications

Acute Tox. 4 Oral - Eye Dam. 1 - Skin Corr. 1B - STOT RE 2 Oral

target_organs

Kidney

Storage Class

6.1C - Combustible, acute toxic Cat.3 / toxic compounds or compounds which causing chronic effects

wgk

WGK 1

flash_point_f

167.0 °F - closed cup

flash_point_c

75 °C - closed cup
