M5525

4-(N-Maleimidomethyl)cyclohexanecarboxylic acid N-hydroxysuccinimide ester

≥98%, powder

Synonym(s):

N-Succinimidyl 4-(maleimidomethyl)cyclohexanecarboxylate, SMCC

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Empirical Formula (Hill Notation):
C16H18N2O6
CAS Number:
64987-85-5
Molecular Weight:
334.32
UNSPSC Code:
12352103
NACRES:
NC.07
PubChem Substance ID:
24897020
MDL number:
MFCD00009634
Beilstein/REAXYS Number:
1555271
Assay:
≥98%
Form:
powder

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

InChI

1S/C16H18N2O6/c19-12-5-6-13(20)17(12)9-10-1-3-11(4-2-10)16(23)24-18-14(21)7-8-15(18)22/h5-6,10-11H,1-4,7-9H2

SMILES string

O=C(ON1C(CCC1=O)=O)C2CCC(CN3C(C=CC3=O)=O)CC2

InChI key

JJAHTWIKCUJRDK-UHFFFAOYSA-N

assay

≥98%

form

powder

reaction suitability

reagent type: linker

mp

180-182 °C (lit.)

solubility

chloroform: 50 mg/mL, DMF: soluble

functional group

NHS ester

shipped in

wet ice

storage temp.

−20°C

Quality Level

200

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

4-(N-Maleimidomethyl)cyclohexanecarboxylic acid N-hydroxysuccinimide ester (SMCC) is a heterobifunctional cross-linking reagent incorporating an extended spacer with amine and sulfhydryl reactivity. It is typically coupled initially to molecules containing primary amine by amide bond buffered at pH 7.5 (6.5-8.5). The second coupling is specific for molecules containing free sulfhydryl by thioether linkage buffered at pH 6.8 (6.5-7.0). SMCC contains nine atom linker. An extended aliphatic spacer stabilizes the maleimide prior to coupling compared to aromatic spacers.

Application

4-(N-Maleimidomethyl)cyclohexanecarboxylic acid N-hydroxysuccinimide ester (SMCC) is useful for the preparation of enzyme immunoconjugates and hapten carrier molecule conjugates. It has been used for the coupling of a peptide sequence to an amino group.

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number
0000527629
0000527628
0000527630
0000527628
0000527629

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Ahmed H
Principles and Reactions of Protein Extraction, Purification, and Characterization (2004)
David A Elsemore et al.
Journal of veterinary diagnostic investigation : official publication of the American Association of Veterinary Laboratory Diagnosticians, Inc, 29(5), 645-653 (2017-04-21)
We report the development and field validation of 2 ELISAs for the detection of Ancylostoma caninum or Toxocara canis coproantigens in the feces of dogs with experimental and natural infections, and evidence of cross-reactivity with respective feline counterparts. A. caninum-specific
Functionalization and cellular uptake of boron carbide nanoparticles. The first step toward T cell-guided boron neutron capture therapy.
Mortensen MW
Bioconjugate Chemistry, 17, 284-284 (2006)
Dieke van Dinther et al.
Cancers, 11(2) (2019-02-16)
The lack of tumor-reactive T cells is one reason why immune checkpoint inhibitor therapies still fail in a significant proportion of melanoma patients. A vaccination that induces melanoma-specific T cells could potentially enhance the efficacy of immune checkpoint inhibitors. Here
Matthias Kuhlmann et al.
Molecular therapy. Nucleic acids, 9, 284-293 (2017-12-17)
The long blood circulatory property of human serum albumin, due to engagement with the cellular recycling neonatal Fc receptor (FcRn), is an attractive drug half-life extension enabling technology. This work describes a novel site-specific albumin double-stranded (ds) DNA assembly approach
