149063

二氢氧化1,3-二[4-(二甲氨基)苯基]-2,4-二羟基环丁烯二鎓二(内盐)

Dye content 90 %

别名:

方酸菁染料 III

登录 查看组织和合同定价。

选择尺寸

关于此项目

经验公式（希尔记法）:
C20H20N2O2
化学文摘社编号:
43134-09-4
分子量:
320.39
NACRES:
NA.23
PubChem Substance ID:
24848931
UNSPSC Code:
12352103
MDL number:
MFCD00142504

主要文件

查看所有文档
技术服务
需要帮助？我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助
技术服务
需要帮助？我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助

form

solid

InChI

1S/C20H20N2O2/c1-21(2)15-9-5-13(6-10-15)17-19(23)18(20(17)24)14-7-11-16(12-8-14)22(3)4/h5-12H,1-4H3

SMILES string

CN(C)c1ccc(cc1)C2=C([O-])C(=C3/C=CC(\C=C3)=[N+](\C)C)\C2=O

InChI key

HERJDZWHZQOZLU-UHFFFAOYSA-N

composition

Dye content, 90%

mp

>300 °C (lit.)

λmax

625 nm

General description

1,3-Bis[4-(dimethylamino)phenyl]-2,4-dihydroxycyclobutenediylium dihydroxide, bis(inner salt) is an organic dye with an electron withdrawing squaraine as the central group and strong electron donating dimethylaminophenyl groups. It is majorly utilized in the development of organic electronic devices.

pictograms

Exclamation mark
GHS07

signalword

Warning

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

target_organs

Respiratory system

存储类别

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves

历史批次信息供参考:

分析证书(COA)

Lot/Batch Number
MKBG1223V
04721KE
16518MI
10111CU
03008PG

没有发现合适的版本？

如果您需要特殊版本，可通过批号或批次号查找具体证书。

搜索COA

已有该产品？

在文件库中查找您最近购买产品的文档。

访问文档库

An MNDO and CNDO/S (S+ DES CI) study on the structural and electronic properties of a model squaraine dye and related cyanine
Bigelow RW and Freund H
Chemical Physics, 107(2-3), 159-174 (1986)
Shingo Saito et al.
Sensors (Basel, Switzerland), 12(5), 5420-5431 (2012-07-11)
Fluorescence sensing of saccharides and glycoproteins using a boronic acid functionalized squarylium cyanine dye ("SQ-BA") is characterized in terms of synthetic, fluorometric, thermodynamic and kinetic parameters. In our previous work, this newly synthesized dye was successfully applied to the separation
Anisotropy in Third-Order Nonlinear Optical Susceptibility of a Squarylium Dye in a Nematic Liquid Crystal
Zhao-Hui, Jin, et al.
Chinese Physics Letters, 23(3), 635-635 (2006)
Photophysical properties of commercial red dyes in polymer films
Burgess IB, et al.
Optical Materials, 30(10), 1478-1483 (2008)
A long-wavelength fluorescent squarylium cyanine dye possessing boronic acid for sensing monosaccharides and glycoproteins with high enhancement in aqueous solution
Saito, Shingo, et al.
Sensors, 12(5), 5420-5431 (2012)
