307696

酞菁钴(II)

β-form, Dye content 97 %

别名:

PcCo, 酞菁 钴(II) 盐, 酞菁素钴

登录 查看组织和合同定价。

选择尺寸

变更视图

关于此项目

经验公式（希尔记法）:
C32H16CoN8
化学文摘社编号:
3317-67-7
分子量:
571.46
UNSPSC Code:
12352103
NACRES:
NA.23
PubChem Substance ID:
24858616
EC Number:
222-012-7
Beilstein/REAXYS Number:
4121847
MDL number:
MFCD00010718
技术服务
需要帮助？我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助

Quality Level

200

form

powder

composition

Dye content, 97%

SMILES string

[Co]1n2c3nc4nc(nc5n1c(nc6nc(nc2c7ccccc37)c8ccccc68)c9ccccc59)c%10ccccc4%10

InChI

1S/C32H16N8.Co/c1-2-10-18-17(9-1)25-33-26(18)38-28-21-13-5-6-14-22(21)30(35-28)40-32-24-16-8-7-15-23(24)31(36-32)39-29-20-12-4-3-11-19(20)27(34-29)37-25;/h1-16H;/q-2;+2

InChI key

MPMSMUBQXQALQI-UHFFFAOYSA-N

General description

酞菁钴是一种金属酞菁。

Application

CoPC的自组装分子沉积在外延石墨烯上。 CoPC可用于开发炭黑电催化剂。 CoPC改性碳胶可用作电催化安培计测量的指示剂。 用CoPC浸渍的ZnO可作为敏化剂，用于确定氰化物在水性悬浮液中的光降解。 已经研究了CoPC催化的醛和酮的需氧再生。 CoPC也可用作超支化聚芳醚酮的封端剂，用于2,4,6-三氯苯酚的氧化分解。

pictograms

Health hazard
GHS08

signalword

Warning

hcodes

H351

Hazard Classifications

Carc. 2

存储类别

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

Eyeshields, Gloves, type P3 (EN 143) respirator cartridges

历史批次信息供参考:

分析证书(COA)

Lot/Batch Number
0000529836
0000529828
0000529828
0000529836
0000486440

没有发现合适的版本？

如果您需要特殊版本，可通过批号或批次号查找具体证书。

搜索COA

已有该产品？

在文件库中查找您最近购买产品的文档。

访问文档库

The use of copper and cobalt phthalocyanines as electrocatalysts for the oxygen reduction reaction in acid medium.
Reis RM, et al.
Electrochimica Acta, 139, 1-6 (2014)
R M Pemberton et al.
Biosensors & bioelectronics, 42, 668-677 (2012-12-26)
A water-based carbon screen-printing ink formulation, containing the redox mediator cobalt phthalocyanine (CoPC) and the enzyme glucose oxidase (GOx), was investigated for its suitability to fabricate glucose microbiosensors in a 96-well microplate format: (1) the biosensor ink was dip-coated onto
Tatsuhiko Honda et al.
Journal of the American Chemical Society, 134(9), 4196-4206 (2012-02-04)
Proton-coupled electron-transfer reduction of dioxygen (O(2)) to afford hydrogen peroxide (H(2)O(2)) was investigated by using ferrocene derivatives as reductants and saddle-distorted (α-octaphenylphthalocyaninato)cobalt(II) (Co(II)(Ph(8)Pc)) as a catalyst under acidic conditions. The selective two-electron reduction of O(2) by dimethylferrocene (Me(2)Fc) and decamethylferrocene
