Merck
CN

334103

Sigma-Aldrich

氮化硅

powder, ≥99.9% trace metals basis

别名:

Trisilicon tetranitride

登录查看公司和协议定价

选择尺寸


关于此项目

线性分子式:
Si3N4
化学文摘社编号:
分子量:
140.28
EC 号:
MDL编号:
UNSPSC代码:
12352300
PubChem化学物质编号:
NACRES:
NA.23
技术服务
需要帮助?我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助
技术服务
需要帮助?我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助

质量水平

方案

≥99.9% trace metals basis

表单

powder

粒径

<1 μm

密度

3.44 g/mL at 25 °C (lit.)

SMILES字符串

N12[Si]34N5[Si]16N3[Si]25N46

InChI

1S/N4Si3/c1-5-2-6(1)3(5)7(1,2)4(5)6

InChI key

HQVNEWCFYHHQES-UHFFFAOYSA-N

正在寻找类似产品? 访问 产品对比指南

一般描述

氮化硅基陶瓷具有较高的断裂韧性、硬度和耐磨性、耐腐蚀性、热稳定性已知的氮化硅多晶型有两种,α和β Si3N4,它们都具有六方结构。一项研究表明,研究人员还合成了第三种形态,立方尖晶石结构。

储存分类代码

11 - Combustible Solids

WGK

nwg

闪点(°F)

Not applicable

闪点(°C)

Not applicable

个人防护装备

dust mask type N95 (US), Eyeshields, Gloves


历史批次信息供参考:

分析证书(COA)

Lot/Batch Number

没有发现合适的版本?

如果您需要特殊版本,可通过批号或批次号查找具体证书。

已有该产品?

在文件库中查找您最近购买产品的文档。

访问文档库

Synthesis of cubic silicon nitride
Zerr A, et al
Nature, 400, 340-342 null
Silicon Nitride and Related Materials
Riley FR
Journal of the American Ceramic Society. American Ceramic Society, 83(2), 245-265 (2000)
Chang-Hyun Park et al.
Optics express, 20(21), 23769-23777 (2012-11-29)
A nanophotonic polarization-independent visible wavelength filter is presented, incorporating a symmetric metal-dielectric resonant structure on quartz substrate, where a sub-wavelength grating, made up of a two-dimensional array of Al square sheets, is integrated with a Si(3)N(4) slab waveguide via an
Simone P Rodrigues et al.
Journal of materials science. Materials in medicine, 24(1), 231-239 (2012-10-12)
Commercial femoral head prostheses (cobalt-chromium alloy, yttria partially stabilized zirconia (Y-PSZ) and alumina) and new silicon nitride ceramic ones (nanocrystalline diamond coated and uncoated) were compared in terms of artifact level production by computed tomography (CT). Pelvis examination by CT
Paolo Pintus et al.
Optics express, 21(4), 5041-5052 (2013-03-14)
In this paper, we present two four-port optical circulators for TE and TM modes, respectively. Exploiting the recent technological development concerning Ce:YIG pulse laser deposition on silicon nitride platform, we design two integrated circulators, which can be used to implement
