N818

1,4,5,8-萘四甲酸酐

别名:

NTCDA

登录 查看组织和合同定价。

选择尺寸


关于此项目

经验公式(希尔记法):
C14H4O6
化学文摘社编号:
分子量:
268.18
UNSPSC Code:
12162002
NACRES:
NA.23
PubChem Substance ID:
EC Number:
201-342-5
Beilstein/REAXYS Number:
272788
MDL number:
技术服务
需要帮助?我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助
技术服务
需要帮助?我们经验丰富的科学家团队随时乐意为您服务。
让我们为您提供帮助

InChI

1S/C14H4O6/c15-11-5-1-2-6-10-8(14(18)20-12(6)16)4-3-7(9(5)10)13(17)19-11/h1-4H

InChI key

YTVNOVQHSGMMOV-UHFFFAOYSA-N

SMILES string

O=C1OC(=O)c2ccc3C(=O)OC(=O)c4ccc1c2c34

form

powder

mp

>300 °C (lit.)

semiconductor properties

N-type (mobility=0.003 cm2/V·s)

Quality Level

正在寻找类似产品? 访问 产品对比指南

General description

1,4,5,8-萘四羧二酸酐(NTCDA)是一种四官能单体,可用作有机电子器件中的电子传输材料。

Application

n-沟道有机半导体。
NTCDA可用于制造各种设备,例如燃料电池、薄膜晶体管(OTFT)、锂离子电池和有机光伏电池(OPV)。

pictograms

Exclamation mark

signalword

Warning

Hazard Classifications

Eye Irrit. 2 - Skin Irrit. 2 - Skin Sens. 1 - STOT SE 3

target_organs

Respiratory system

存储类别

11 - Combustible Solids

wgk

WGK 2

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves


历史批次信息供参考:

分析证书(COA)

Lot/Batch Number

没有发现合适的版本?

如果您需要特殊版本,可通过批号或批次号查找具体证书。

已有该产品?

在文件库中查找您最近购买产品的文档。

访问文档库

Efficient p-i-n type organic solar cells incorporating 1, 4, 5, 8-naphthalenetetracarboxylic dianhydride as transparent electron transport material
Falkenberg C, et al.
Journal of Applied Physics, 104(3), 034506-034506 (2008)
Electrochemical performance of sol-gel synthesized LiFePO4 in lithium batteries
Hu Y, et al.
Journal of the Electrochemical Society, 151(8), A1279-A1285 (2004)
Mohammad A Jafar Mazumder et al.
Scientific reports, 10(1), 7049-7049 (2020-04-29)
Sulfonated homo and co- polyimide (sPI) were synthesized with new compositional ratios, and used as additives (0.5 wt%, 0.75 wt%, and 1.0 wt%) to prepare blend membranes with polysulfone (PSf). Flat sheet membranes for ultrafiltration (UF) were casted using the phase inversion technique.
Multi-parameter gas sensors based on organic thin-film-transistors
Torsi L, et al.
Sensors and Actuators B, Chemical, 67(3), 312-316 (2000)
Tankut Türel et al.
ChemPlusChem, 85(7), 1430-1437 (2020-07-08)
Naphthalene diimide (NDI) compounds are widely used as electron acceptors in various applications. Herein, we combine NDI with quaternary ammonium groups for the synthesis of a highly electron-deficient linear compound 2 and macrocycle 3. The complexation studies of the water-soluble
