807113

TSKgel® HXL (6 µm) HPLC Columns

L x I.D. 4 cm × 6 mm, polystyrene-divinylbenzene phase

Synonym(s):

TSKgel® G1000HXL HPLC Column for Light Scattering Applications

Sign In to View Organizational & Contract Pricing.

Select a Size

Change View

About This Item

UNSPSC Code:
41115700
eCl@ss:
32110501
NACRES:
NB.21
L × i.d.:
4 cm × 6 mm
Particle size:
6 μm
Matrix active group:
polymer, polystyrene-divinylbenzene phase
Pore size:
mixed
Matrix:
polymer particle platform
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

TSKgel® HXL Guard Column, phase polystyrene-divinylbenzene, L × I.D. 4 cm × 6 mm, 6 μm particle size

material

stainless steel

product line

TSKgel®

mol wt

All molecule sizes

manufacturer/tradename

Tosoh 07113

parameter

1.2 mL/min flow rate, 60 °C temperature

technique(s)

HPLC: suitable

L × I.D.

4 cm × 6 mm

matrix

polymer particle platform

matrix active group

polymer, polystyrene-divinylbenzene phase

particle size

6 μm

pore size

mixed

separation technique

size exclusion (SEC)

General description

The TSKgel® HXL column line consists of eight columns with different pore sizes, TSKgel G1000HXL through TSKgel G7000HXL, and three columns with an extended linear range of the calibration curve, TSKgel GMHXL, TSKgel GMHXL-L and TSKgel MultiporeHXL-M. The calibration curves are shown to the right. Main characteristics are: ultra-low sample adsorption, i.e., the columns show true size exclusion behavior for most polymers, maximum operating temperature for TSKgel HXL-type columns is 60°C for G1000HXL, G2000HXL, G2500HXL and G3000HXL, and 80°C for the remaining columns in the product line. See TSKgel HHR HT columns for operating temperatures of 140°C, the columns are shipped in THF, which can be exchanged for a limited number of organic solvents. TSKgel HXL-type columns are conventional GPC columns with column dimensions of 7.8mm ID x 30cm.

Physical form

Shipped in THF.

Other Notes

Discover LiChropur reagents ideal for HPLC or LC-MS analysis
THF can be replaced with benzene, chloroform, toluene, xylene, dichloromethane, dichloroethane

Legal Information

TSKgel is a registered trademark of Tosoh Corporation
