123463

1,2-Cyclohexanedicarboxylic anhydride, predominantly cis

Name: 1,2-Cyclohexanedicarboxylic anhydride, predominantly <I>cis</I>
Brand: ALDRICH

95%

Synonym(s):

Hexahydrophthalic anhydride

Select a Size

Change View

About This Item

Empirical Formula (Hill Notation):

C₈H₁₀O₃

CAS Number:

85-42-7

Molecular Weight:

154.16

NACRES:

NA.23

PubChem Substance ID:

24847568

UNSPSC Code:

12162002

EC Number:

201-604-9

MDL number:

MFCD00005926

Technical Service

Need help? Our team of experienced scientists is here for you.

Let Us Assist

Properties

Quality Level

100

assay

95%

form

solid

bp

158 °C/17 mmHg (lit.)

mp

32-34 °C (lit.)

SMILES string

O=C1OC(=O)[C@H]2CCCC[C@@H]12

InChI

1S/C8H10O3/c9-7-5-3-1-2-4-6(5)8(10)11-7/h5-6H,1-4H2/t5-,6+

InChI key

MUTGBJKUEZFXGO-OLQVQODUSA-N

Description

General description

Predominantly cis 1,2-cyclohexanedicarboxylic anhydride (HHPA) is a cyclic anhydride that can be used for a variety of applications such as: plasticizer, rust inhibitor, and a curing agent for epoxy based resins.

Application

HPPA, in combination with triethaylamine (TEA), can be used as a polymerization initiator in the preparation of polyester based resins. It can also be used as a hardener to cure 1,4-butanediol diglycidyl ether which can be used as an epoxy based system for electronic devices.

pictograms

GHS08,GHS05

signalword

Danger

hcodes

H317,H318,H334

pcodes

P261 - P272 - P280 - P284 - P302 + P352 - P305 + P351 + P338

Hazard Classifications

Eye Dam. 1 - Resp. Sens. 1 - Skin Sens. 1

Storage Class

11 - Combustible Solids

wgk

WGK 1

ppe

dust mask type N95 (US), Eyeshields, Faceshields, Gloves

Choose from one of the most recent versions:

Certificates of Analysis (COA)

Lot/Batch Number

Don't see the Right Version?

If you require a particular version, you can look up a specific certificate by the Lot or Batch number.

Search for a COA

Already Own This Product?

Find documentation for the products that you have recently purchased in the Document Library.

Visit the Document Library

Serum albumins are the major site for in vivo formation of hapten-carrier protein adducts in plasma from humans and guinea-pigs exposed to type-1 allergy inducing hexahydrophthalic anhydride.

G Johannesson et al.

Clinical and experimental allergy : journal of the British Society for Allergy and Clinical Immunology, 31(7), 1021-1030 (2001-07-27)

Organic acid anhydrides (OAAs) are highly allergenic compounds used in the chemical industry. The OAAs probably act as haptens but the proteins that form conjugates with OAAs in vivo are still unknown. Conjugates between the anhydrides and serum albumins (SAs)

Shear horizontal guided wave modes to infer the shear stiffness of adhesive bond layers.

Bénédicte Le Crom et al.

The Journal of the Acoustical Society of America, 127(4), 2220-2230 (2010-04-08)

This paper presents a non-destructive, ultrasonic technique to evaluate the quality of bonds between substrates. Shear-horizontally polarized (SH) wave modes are investigated to infer the shear stiffness of bonds, which is necessarily linked to the shear resistance that is a

Effect of respiratory protective devices on development of antibody and occupational asthma to an acid anhydride.

Leslie C Grammer et al.

Chest, 121(4), 1317-1322 (2002-04-12)

To determine whether the use of respiratory protective equipment would reduce the incidence of occupational asthma due to exposure to hexahydrophthalic anhydride (HHPA). Prospective cohort study. A facility that makes an epoxy resin product requiring HHPA for its manufacture. Sixty-six
