221171

Sigma-Aldrich

Pinacol

98%

Sign Into View Organizational & Contract Pricing
All Photos(3)
Synonym(s):
2,3-Dimethyl-2,3-butanediol, Tetramethylethylene glycol
Linear Formula:
HOC(CH3)2C(CH3)2OH
CAS Number:
76-09-5
Molecular Weight:
118.17
Beilstein:
1340501
EC Number:
200-933-5
MDL number:
MFCD00004462
PubChem Substance ID:
24853219
NACRES:
NA.22

Quality Level

200

Assay

98%

form

solid

bp

171-172 °C/739 mmHg (lit.)

mp

40-43 °C (lit.)

solubility

alcohol: freely soluble
diethyl ether: freely soluble
hot water: freely soluble

SMILES string

CC(C)(O)C(C)(C)O

InChI

1S/C6H14O2/c1-5(2,7)6(3,4)8/h7-8H,1-4H3

InChI key

IVDFJHOHABJVEH-UHFFFAOYSA-N

Looking for similar products? Visit Product Comparison Guide

Related Categories

General description

The pinacol coupling reaction with the inorganic electride [Ca2N](+)·e(−) as an electron donor in organic solvents was studied.

Application

Pinacol is a 1,2-diol that can be used:
  • As a ligand to prepare uranyl complexes by reacting with uranyl nitrate and acetate hydrates.
  • To prepare pinacolone and 2,3-dimethyl-1,3-butadiene by typical pinacol rearrangement reaction.
  • As a reactant to synthesize 4-(4,4,5,5-tetramethyl-1,3,2-bioxaborolan-2-yl)benzoic acid, which is used to prepare derivatives of 4-acetoxy-3-phenylbenzaldehyde.

Storage Class Code

11 - Combustible Solids

WGK

WGK 2

Flash Point(F)

170.6 °F

Flash Point(C)

77 °C

Personal Protective Equipment

dust mask type N95 (US), Eyeshields, Gloves

Certificates of Analysis (COA)

Search for Certificates of Analysis (COA) by entering the products Lot/Batch Number. Lot and Batch Numbers can be found on a product’s label following the words ‘Lot’ or ‘Batch’.

Already Own This Product?

Documents related to the products that you have purchased in the past have been gathered in the Document Library for your convenience.

Visit the Document Library

Difficulty Finding Your Product Or Lot/Batch Number?

Product numbers are combined with Pack Sizes/Quantity when displayed on the website (example: T1503-25G). Please make sure you enter ONLY the product number in the Product Number field (example: T1503).

Example:

T1503
Product Number
-
25G
Pack Size/Quantity

Additional examples:

705578-5MG-PW

PL860-CGA/SHF-1EA

MMYOMAG-74K-13

1000309185

enter as 1.000309185)

Having trouble? Feel free to contact Technical Service for assistance.

Lot and Batch Numbers can be found on a product's label following the words 'Lot' or 'Batch'.

Aldrich Products

  • For a lot number such as TO09019TO, enter it as 09019TO (without the first two letters 'TO').

  • For a lot number with a filling-code such as 05427ES-021, enter it as 05427ES (without the filling-code '-021').

  • For a lot number with a filling-code such as STBB0728K9, enter it as STBB0728 without the filling-code 'K9'.

Not Finding What You Are Looking For?

In some cases, a COA may not be available online. If your search was unable to find the COA you can request one.

Request COA

Uranyl complexes with 1, 2-diols and tetrahydrofurfuryl alcohols
Villiers C, et al.
Polyhedron, 46(1), 133-138 (2012)
Ye Ji Kim et al.
Chemical communications (Cambridge, England), 50(37), 4791-4794 (2014-04-02)
The scalable pinacol coupling reaction is realized utilizing the inorganic electride [Ca2N](+)·e(-) as an electron donor in organic solvents. The bond cleavages of the [Ca2N](+) layers by methanol play a vital role in transferring anionic electrons to electrophilic aldehydes, accompanying
Fe-substituted molecular sieves as catalysts in liquid phase pinacol rearrangement
Hsien M, et al.
J. Mol. Catal. A: Chem., 181(1-2), 189-200 (2002)
New extraction procedure for protonated polyoxometalates prepared in aqueous-organic solution and characterisation of their catalytic ability
Ueda T, et al.
Applied Catalysis A: General, 485(1-2), 181-187 (2014)
Synthesis of polymer-bound 4-acetoxy-3-phenylbenzaldehyde derivatives: applications in solid-phase organic synthesis
Kumar A, et al.
The Journal of Organic Chemistry, 71(20), 7915-7918 (2006)
