393541

Gallium(III) acetylacetonate

99.99% trace metals basis

Synonym(s):

Ga(acac)3, Gallium(III) 2,4-pentanedionate

Sign In to View Organizational & Contract Pricing.

Select a Size

About This Item

Linear Formula:
[CH3COCH=C(O-)CH3]3Ga
CAS Number:
14405-43-7
Molecular Weight:
367.05
NACRES:
NA.23
PubChem Substance ID:
24864524
UNSPSC Code:
12352103
EC Number:
238-377-0
MDL number:
MFCD00013492

Key Documents

View All Documentation
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist
Technical Service
Need help? Our team of experienced scientists is here for you.
Let Us Assist

Product Name

Gallium(III) acetylacetonate, 99.99% trace metals basis

InChI key

ZVYYAYJIGYODSD-LNTINUHCSA-K

InChI

1S/3C5H8O2.Ga/c3*1-4(6)3-5(2)7;/h3*3,6H,1-2H3;/q;;;+3/p-3/b3*4-3-;

SMILES string

CC(=O)\C=C(\C)O[Ga](O\C(C)=C/C(C)=O)O\C(C)=C/C(C)=O

assay

99.99% trace metals basis

form

solid

reaction suitability

core: gallium
reagent type: catalyst

mp

196-198 °C (dec.) (lit.)

Quality Level

100

Related Categories

Application

Gallium(III) acetylacetonate can be used:
  • As a precursor to synthesize nanocrystalline gallium oxide spinels via solvothermal process for various applications like photocatalysis, battery cathode materials and electrocatalysis.
  • To fabricate LiGa alloy layer on Li metal anode from in-situ electroreduction. It suppresses the anode dendrite formation in lithium-sulfur batteries.
  • To prepare highly efficient gallium-platinum (GaPt3) nanoparticles hot-solvent synthesis which act as electrocatalysts for hydrogen evolution reaction.
  • To synthesize γ-Ga2O3 nanocrystals for fabricating electron-transporting layer for perovskite solar cells. It forms effective interfacial connections with the perovskite top layer, enhancing the efficiency of charge transport.

Features and Benefits

  • The high purity (99.99% trace metals basis) ensures that no impurities interfere with the synthesis process, leading to higher yields and better quality of the gallium compounds.
  • High purity enhances catalytic activity and selectivity, reducing the formation of by-products and improving overall reaction efficiency.
  • The absence of trace metal impurities ensures the integrity and performance of the thin films, resulting in improved device efficiency and longevity of optoelectronic devices.
  • The high purity of the precursor minimizes defects and impurities in the semiconductor materials, enhancing their electrical properties and performance.

General description

Gallium(III) acetylacetonate is a white to off-white crystalline solid with purity (99.99% trace metals basis) widely used as a precursor for thin films and nanomaterials. It is soluble in organic solvents such as ethanol, acetone, and toluene, making it suitable for solution-based nanoparticle synthesis. Its thermal stability, with decomposition occurring above ~200 °C, allows for controlled gallium release, making it ideal for the synthesis of nanomaterials and oxide layers. It is commonly employed in metal-organic chemical vapor deposition (CVD) and atomic layer deposition (ALD) to produce gallium oxide (Ga₂O₃) and gallium nitride (GaN) thin films, which are essential for electronic and optoelectronic applications.

pictograms

Health hazardExclamation mark
GHS08,GHS07

signalword

Warning

Hazard Classifications

Acute Tox. 4 Dermal - Acute Tox. 4 Inhalation - Acute Tox. 4 Oral - Carc. 2 - Eye Irrit. 2 - Skin Irrit. 2 - STOT SE 3

target_organs

Respiratory system

Storage Class

11 - Combustible Solids

wgk

WGK 3

flash_point_f

Not applicable

flash_point_c

Not applicable

ppe

dust mask type N95 (US), Eyeshields, Gloves
