description
Loading Density: 30%-70% (TiO2 nanocrystal) by TEM, resistance: <103 Ω/sq (graphene)
form
dispersion (in acetone), dispersion
concentration
10 mg/mL in acetone, 10 mg/mL
thickness
1-10 nm , graphene
particle size
10-40 nm (TiO2 nanocrystal)
storage temp.
2-8°C
General description
TiO2/graphene composite is highly crystalline graphene sheets hybridized with titanium oxide nanocrystals. The graphene sheets act as substrate and thickness is about 1~10 nm. The attached particle size of TiO2 is between 10-40 nm, and the loading density is in the range of 30%-70%. X-ray diffraction pattern confirms that the graphene sheets are well crystallized and the attached particles are TiO2.
Application
- Photocatalyst
- Dye sensitized solar cells
Legal Information
Product of Ocean Nanotech, LLC.
signalword
Danger
hcodes
Hazard Classifications
Eye Irrit. 2 - Flam. Liq. 2 - STOT SE 3
target_organs
Central nervous system
supp_hazards
存储类别
3 - Flammable liquids
wgk
WGK 1
flash_point_f
1.4 °F
flash_point_c
-17 °C
法规信息
新产品
此项目有
Enhanced photovoltaic performance of dye-sensitized solar cells based on TiO2 nanosheets/graphene composite films
Fan et al.
Journal of Materials Chemistry, 22(33), 17027-17036 (2012)
Yanhui Zhang et al.
ACS nano, 4(12), 7303-7314 (2010-12-02)
The nanocomposites of TiO(2)-graphene (TiO(2)-GR) have been prepared via a facile hydrothermal reaction of graphene oxide and TiO(2) in an ethanol-water solvent. We show that such a TiO(2)-GR nanocomposite exhibits much higher photocatalytic activity and stability than bare TiO(2) toward
Hao Zhang et al.
ACS nano, 4(1), 380-386 (2010-01-01)
Herein we obtained a chemically bonded TiO(2) (P25)-graphene nanocomposite photocatalyst with graphene oxide and P25, using a facile one-step hydrothermal method. During the hydrothermal reaction, both of the reduction of graphene oxide and loading of P25 were achieved. The as-prepared
